Accessories for Battery Test
High current cylindrical battery jig
  • Battery jig is for single cell high current cylindrical battery test
  •

      응용 분야



    Features

    These battery jig is for single cell high current cylindrical battery test and having length
    adjustable function. For this purpose these should be designed for kelvin type 4 probe
    connection to minimize voltage drop by cable resistance and/or contact resistance etc.
    There are two type of High current Cylindrical Battery Jig by battery length One is model
    HCCBJ65L for standard size battery up to 65mm length and the other is model
    HCCBJ100L for long size battery up to 100mm length.



    제품 사양

    • Maximum battery diameter : 30 mm
    • Minimum battery contact diameter : 14mm
    • Maximum battery length : HCCBJ65L - 65 mm, HCCBJ100L - 100 mm
    • Current path diameter : 14mm
    • Minimum battery length : 1 mm
    • Length × Width × Height : HCCBJ65L - 136x24x43 mm, HCCBJ100 - 172x24x43 mm
    • Cable Connectors : 4ea of 4mm banana
    • Weight : HCCBJ65L - 208 g, HCCBJ100L - 240 g





    Ordering Guide

    Description Part No.
    High current cylindrical battery jig
    - max. battery length : 65mm
    HCCBJ65L
    High current cylindrical battery jig
    - max. battery length : 100mm
    HCCBJ100L





    제품 이미지

    HCCBJ65L



    HCCBJ100L
